Is there a problem with my 3 way Dometic fridge?

Righto putting the call out hoping someone can assist…..My 3 way Dometic fridge is one that has the auto start AES set up, works fine on gas and 240 but can’t get it to switch to 12v, no problem with 12v supply as far as the relay but unable to get the fridge to recognise 12v supply from vehicle so it will activate 12v fridge setting.

Can a Dometic fridge work on 12V voltage?

Our dometic and this thetford work really well on 12v actually the dometic would freeze down on 12v you just had to make sure it was getting all the voltage available? (I ran 13mm sq right through ) Thanks again @millers I didn’t turn up that info on any of the searches I have done……….

Where was the fuse blown on the Dometic RV refrigerator?

TROUBLESHOOTING DOMETIC RV REFRIGERATOR 5 amp fuse blown. The 5 amp fuse location is in the back of the Refrigerator was blown causing the appliance to work only on LPG (GAS) mode.

What should the temperature be in a camper fridge?

Next, you need to find a way to read the temperature in the fridge with everything unplugged. To do so, fill a glass of water and add in a thermometer. Put this in the fridge and close the door. Now wait. The temperature should read about 43 degrees Fahrenheit in a 12-hour period. It’s okay if it’s a little lower.

Is the Dometic 2310 a 12 volt refrigerator?

The Dometic 2310 is a three way (propane, 120 volt, 12 volt) refrigerator that was used for many years in Roadtreks. One of its nicest features is that it requires no 12 volt power to run on propane (which is not true of the current models).

What kind of power does a Dometic refrigerator use?

Lighting the Dometic2310 Fridge The Dometic2310 is a three way (propane, 120 volt, 12 volt) refrigerator that was used for many years in Roadtreks. One of its nicest features is that it requires no 12 volt power to run on propane (which is not true of the current models).

Can a AC / DC Dometic refrigerator be troubleshooting?

AC/DC model Dometic refrigerators are fairly simple in troubleshooting. You will know that you have one of these models if the refrigerator has a compressor in the back (typically installed in boats and trucks). Most RV’s have gas absorption refrigerators and these can be more troublesome since there are more components that affect the cooling.

Where is the baffle on a Dometic refrigerator?

The baffle is inside the flue. Use an air compressor to blow air into the flue. Continue to use the air compressor to remove dust and debris that has built up around the compartment. I hope some of these basic Dometic refrigerator parts and troubleshooting tips can get you back on the road quickly. What do you think?

What’s the electric mode on a Dometic refrigerator?

Any advice/suggestions you can provide will be most appreciated. The electric mode is 120V & when you’re hooked up for travel you have 12v. Make sure you have propane and if so, turn it back on. If not, go buy some & see if it works then.

How to troubleshoot a Dometic EA 3120 refrigerator?

Dometic EA 3120 refrigerator troubleshooting 1 Immediately turn the refrigerator off. 2 Open windows and door to air out the coach and evacuate. 3 Contact a Dometic dealer or Service Center. 4 Do not use the refrigerator until it has been repaired.

Why does my Dometic refrigerator make water gurgling noise?

Hi Pearl, Have a Dometic RM2611 All lights work on front of unit, both gas and AC. On gas the burner lights and everything gets warm, coils and inside. You can hear water gurgling noise. Everything st… read more Appliance Guru 23,516 satisfied customers

Why does my Dometic RV fridge not turn on?

My Dometic RM2652 RV fridge will not turn on, I have lights inside the fridge, but no lights on the eyebrow panel inside the camper at the top of the fridge, any help on what this could be would be great, thanks.

What to do if your Dometic wont turn on?

Insure there are no blown glass fuses on the control circuit board and battery voltage is adequate. Check the voltage in the rear where the 12 VDC power circuit is attached.

How to troubleshoot the back of a Dometic refrigerator?

Okay, now let’s move on to trouble shooting techniques. Check all the circuit breakers and fuses. Check the outlet on the back of the refrigerator. Use a multi meter to check for power voltage. If the voltage checks out okay and all lights work, then check the electric heating element. Beware this has dangerous voltage…. Check the flame.

How many volts does a Dometic refrigerator need?

The unit will automatically shut down at 22 DC volts or greater, and come back on when voltage has decreased to 18 volts DC. The refrigerator requires at least 9.6 volts DC for proper operation, however the panel lights will continue to be illuminated until voltage has dropped to 4 volts DC or below.

Where are the fuses on a Dometic refrigerator?

I found 3 fuses on the back of the fridge. There were 2 blade style fuses and one automotive style glass fuse. Two of the three were under the circuit board cover. All fuses tested good visually and for continuity. Was 12 VDC present at the rear of the fridge?

Where is the power block on a Dometic fridge?

You should find that terminal block on the floor of the space inside of the rear access panel and usually, it is to the left side, near the 120V power outlet. If you do not have power there, you must find what the course is.

How to troubleshoot a dm2652 Dometic refrigerator?

Dometic DM2652 refrigerator troubleshooting 1 • LP gas bottle empty? Change the gas bottle. 2 • Air in the gas line? Remove the air by repeating the ignition sequence. 3 • If problem resists, turn refrigerator off and contact a Dometic dealer or Service Center for repair. More …

What to do if Dometic refrigerator burner breaks?

• Disconnect the 120 VAC power at rear of refrigerator. • Contact a Dometic dealer or Service Center for repair. • Do not use the refrigerator until it has been repaired. • Dislocated or damaged burner.

Is there a problem with my Dometic fridge?

Long story – but I am at Coolgardie at the moment assisting a family member with a medical problem. His mate has a Dometic RM4605/4805 3-way AES and the AES activates properly and detects whether 240v or 12v is connected – if not connected it selects the auto start for the gas, clicks and the gas fires up.

What kind of AES does Dometic rm4605 / 4805 have?

His mate has a Dometic RM4605/4805 3-way AES and the AES activates properly and detects whether 240v or 12v is connected – if not connected it selects the auto start for the gas, clicks and the gas fires up. However, after a short time the gas just cuts out.

Where can I buy spare parts for my Dometic?

Our Dometic Fridge & Freezer Spare Parts range is available for delivery worldwide. You can easily buy Dometic Fridge & Freezer Spare Parts from our huge in stock Fridge & Freezer Spare Parts range at Spares2Repair. We have all the spare parts you need for your Dometic in our Fridge & Freezer Spare Parts and accessories range.

Is there a reset button on the Dometic refrigerator?

Finding Dometic RV Refrigerator Reset Button & Using It! Finding Dometic RV Refrigerator Reset Button & Using It! Proud owners of Dometic RV refrigerator are almost always stress- free with their camping trips. But sometimes the situation does not go according to plans, and that’s pretty normal.

Why does my Dometic fridge not turn on?

The AC sensing circuit is not turning the power on when Auto is selected. It may not be sensing AC incoming or it is not switching it on. On switch causes it to start but it will only start in gas. It cannot be set to auto, it momentarily blinks the indicator for auto then goes straight to gas.

What kind of power does a Dometic refrigerator need?

The refrigerator has to have 12 volts power to run on propane, or 120 volt power to run without propane. The coach batteries must be fully charged. Also, try resetting the check on lights. Do this by powering off, counting to 10, then turning back on again.

Where are the 12 VDCs on a Dometic fridge?

Its good you checked the 12 VDC distribution panel (and any fuse to fridge) where all the fuses are that serve the entire coach,. If 12 VDC is present there and through any fuse (or a branch circuit) to the fridge, it ought to be present at the very input to the fridge itself unless there’s a bad ground or a wiring or terminal problem/open.
